Eton PW8

Nominal impedance
Zn
2x2
Ω
Total moving mass (incl. air mass)
MMD
105.00
g
DC resistance
Re
3.8
Ω
Effective piston area
SD
190
cm2
Voice coil inductance
Le
1.64
mH
Resonance frequency TSP
fr
37
Hz
Force factor
BLxl
13.56
Tm
Suspension compliance
CMS
0.18
mm/N
Mechanical Q
QMS
5.84
Xmax mechanical
+/-
37.0
mm
Electrical Q
QES
0.56
Equivalent air vol. of suspension
VAS
8.99
dm3
Total Q
QTS
0.51
Characteristic SPL 1W / 1 m
81
dB
Mechanical resistance
RMS
4.20
kg/s
Rated power
300/400
W
magnet material
-
Ferrit
-
voice coil diameter
50
mm
