Edge EDS8DSP-E3

EDS8DSP-E3
Type: 8 channel DSP Processor
Dimensions (H x W x D):  1.6” x 5.3” x 5.2”,(40 x 135 x 131mm)
Frequency Response: 10Hz - 30kHz
Crossover Type: LP / HP / BP / Flat
LP Crossover Range:V20Hz - 20kHz
HP Crossover Range: 20Hz - 20k

Dimensions (H x W x D): 1.6" x 5.3" x 5.2" (40mm x 135mm x 131mm)

Features

Cast aluminium chassis
Auto turn on circuit
High and low level input
Optical and coaxial digital input
Audio streaming receiver
8 channel RCA output
Master volume control via smartphone app
Source input switching from High level, RCA, optical digital and wireless streaming
1/3 octave parametric equaliser with variable Q
High pass, low pass and bandpass crossover for each channel with variable crossover slope up to 48dB per octave
Phase control
Time alignment for each channel
Powerful mixer allows summing of input signal and distribution to any channel
Limiter allows full control over system dynamics
Real time adjustment from the drivers seat allowing easy setup after installation
All features can be adjusted with intuitive gesture control
